SY305C

STRONG POWERFUL

TOP HIGHLIGHTS

+ 10″ touchscreen display
+ 2 cameras
+ Seat with adjustable control panels
+ 5 different attachment devices can
+ be programmed for each category

Class

Crawler Excavator

Engine

CUMMINS QSL9-C280

Operating mass

32 265 kg

Download
message
Email
BENEFITS & FEATURES

QUALITY

Lasting quality – the daily working environment at construction sites is tough. To ensure that SANY excavators can withstand these rigours in the long term, they are designed and produced with particular care. Among other elements, this includes incorporating clean piping and precisely positioned welded seams.

DIMENSIONS

Stable foundation – while the machine is one of the heaviest in its class, operators also have optimal visibility to the rear thanks to the flat design.

USER EXPERIENCE

Innovations set the machine apart – from the first time an operator sits in the new SANY SY305C, they know that it offers a first-rate user experience. From first sight, it is apparent that the driver‘s cab is impressive. Let‘s take the clear 10″ touch display as an example. Its high-resolution screen not only displays a considerable amount of information, it also shows the images from the two cameras. The touch display can also be used for various operating functions, meaning that many of the features are easy to control using just a finger. Moreover, the seating position of the air-suspension driver‘s seat with integrated seat heating can be continuously adjusted. The control elements connected to the seat can be used to make any adjustment, further adding to the ergonomics and user experience.

SAFETY

Good lighting for good visibility – if it starts to get dark, the machine has eight LED work spotlights which provide the best possible illumination. The rear and side cameras transmit the images of the surrounding area to the high-resolution monitor as standard. This ensures that the driver always has the best possible view of the working area and travel path. Another element for improved safety is the machine‘s maintenance platform. It has an anti-slip surface and non-slip handrail, which ensure a secure grip even in wet conditions.

COMPONENTS

Reliable and effective – the drive unit made by Cummins not only embodies the highest degree of reliability, it also boasts innovative exhaust treatment. In order to comply with Stage V emission standards, the unit operates with a combination of SCR and DPF technology. The fact that the exhaust gas is not recirculated significantly increases efficiency, resulting in maximum productivity with minimal fuel consumption. Moreover, the unit has a more compact design because, among other things, additional cooling units are no longer required. This enables the package space to be kept clear for optimal visibility to the rear.

ECONOMY

Everything in sight and within reach – to enable efficient work at the construction site, you can, for example, save the required working pressures and oil flow for up to five attachment devices for each category. Simply enter the name of the tool in the large, high-resolution 10″ touchscreen display and assign the required value to the tool. This makes it quick and easy to change attachment devices on the construction site – enabling significant time and cost savings. In addition, the large touch display allows you to intuitively navigate through the simple menu structure and to monitor all of the important parameters.
TECHNICAL SPECIFICATIONS
DIMENSIONS
Operating mass 32265 kg
Standard bucket capacity 1.7 m³
Transport length 10667 mm
Transport width 2990 (3190**) mm
Height over cabin/ROPS 3225 mm
ENGINE
Rated power 209 kW 2100 rpm
WORKING AREA
Max. digging depth 6815 mm
Max. digging reach 10870 mm
Min. swing radius 4000 mm
Bucket digging force ISO 204 kN
Arm digging force ISO 153 kN
HYDRAULIC SYSTEM
Max. oilflow 2×280 l/min
STANDARD EQUIPMENT
› Heater › Automatic air conditioning C/H* › Radio and speaker › Armrests (adjustable) › Airsuspension seat › Heated seat › Wiper › Sprayer f. wiper › AUX 1 on Joystick › AUX 2 on Joystick › Joysticks independently from seat adjustable › Sky light openable › 10″ touchscreen display * The air conditioner contains fluorinated greenhouse gases: Refrigerant type: HFC-134a, Global warming potential: 1 430, Quantity: 0,9 kg, CO2e: 1,29 t
› Battery master switch › Travel Alarm › Warning beacon › Camera › Side camera › Handrails › Lockablge fuel cap
› Boom and arm load holding valves with overload indicator › Double acting circuit for hydraulic quick coupler with piping › Breaker&Shear line proportional on Joystick with piping › Rotation line proportional on Joystick with piping › Flow adjustment for attachments › Pressure adjustment for attachments
› Lights – front (LED) › Lights – boom (LED) › Lights – platform (LED) › Lights – back (LED)
› Steel tracks › Holes/loops for fixing › HD Line
› Auto idle › DPF › SCR
› Swing brake › 2 speed travel › Piping for additional hydraulic function AUX 1 › Piping for additional hydraulic function AUX 2 › Fuel filler pump with automatic shut-off › Hydr. Pre-pressure operating joysticks › Switchover hammer valve in display
